PRODUCT DETAILS | |
Sizes | 1/2" to 12" |
Pressure Class Ratings | Asme #150 to #300 |
End Connection | Screwed, Flanged |
Construction Types | Single Chamber, Double Chamber others upon request |
Salient Features | Easy Installation, Low Head Loss, High Capacity, Maximum Pipeline Efficiency etc. |
Operator/Actuator | Self Actuation |
STANDARDS SPECIFICATIONS | |
Design & Manufacture | AWWA C512, EN 1074,ASME B16.34 |
Face To Face | MFG Standard |
End Connections | ISO 7-1, BS 21, ASME B1.20.1, ASME B16.5 RF/FF, EN 1092 |
Testing | ASME B16.34 |
Nace | NACE MR0175/ISO 15156 and NACE MR0103/ISO17945 |
MATERIAL OF CONSTRUCTION | |
Body / Cover | Cast Iron, SG Iron, Carbon & Low Carbon Steel, Stainless Steel |
Trim | Stainless Steel, Bronze, others upon request |
Seats | Metal, Natural Rubber, Neoprene, Buna-N, Viton, EPDM, PTFE, NBR etc |
Gaskets | PTFE/RPTFE/Special filled PTFE/Graphite/Graphoil/Rubber |
Fasteners | ASTM A193 Gr.B7/A194 Gr.2H, B7M/2HM, B8/8, B8M/8M, L7/4, B16/2H etc., |
Note : For Bigger sizes please contact PR-Fect Valves
