PRODUCT DETAILS | |
Sizes | 1/2" to 16" |
Pressure Class Ratings | Asme #150 to #600 |
End Connection | Screwed, Flanged |
Construction Types | Full View, Single/Double Window, others upon request |
Salient Features | Various Types of Indicators, Full View etc. |
Operator / Actuator | Self Actuation |
STANDARDS SPECIFICATIONS | |
Design & Manufacture | ASME B16.34 |
Face To Face | MFG Standard |
End Connections | ISO 7-1,BS 21, ASME B1.20.1, ASME B16.5 RF/FF, EN 1092 |
Testing | ASME B16.34 |
Nace | NACE MR0175/ISO 15156 and NACE MR0103/ISO17945 |
MATERIAL OF CONSTRUCTION | |
Body / Connector | Carbon & Low Carbon Steel, Stainless Steel, Nickel alloys, High Temp Alloys, Duplex Stainless Steel, Exotic Materials |
Glass | Toughened borosilicate, Sodalime, Acrylic etc |
Flapper/Wheel | Aluminium, SS, PVC, PP, etc |
Gaskets | PTFE/RPTFE/Special filled PTFE/Rubber |
Fasteners | ASTM A193 Gr.B7/A194 Gr.2H, B7M/2HM, B8/8, B8M/8M, L7/4, B16/2H etc., |
Note : For Bigger sizes please contact PR-Fect Valves
