PRODUCT DETAILS
Sizes	2" to 16 "
Pressure Class Ratings	Asme #600 to #2500
End Connection	Screwed, Socket Weld, Flanged, Butt-Weld
Construction Types	O.S & Y. Rising Stem, Quick-opening Disc,Linear & Equal Characteristic Disc, others upon request
Salient Features	Pressure Seal,Fugitive Emissions,Metal Seats ,Back Seating,Stem,Insitu Seat Extension,Bypass Arrangement,Equalizing Arrangement, Bypass and Equalizing Arrangement,Locking Arrangements etc.
Operator / Actuator	Handwheel, Gear, Actuator (Pneumatic, Hydraulic, Electro-Hydraulic and Electric Motorised)

STANDARDS SPECIFICATIONS
Design & Manufacture	API 623, ASME B16.34
Face To Face	ASME B16.10, MFG Standard
End Connections	ASME B16.11,ISO 7-1,BS 21 ASME B1.20.1,ASME B16.5 RF/ FF/ RTJ ASME 16.25,EN 1092
Testing	API 623, API 598, ASME B16.34
Fire safe testing	ISO 10497/ API 607,API 6FA
Nace	NACE MR0175 / ISO 15156 and NACE MR0103 / ISO17945
Fugitive emission	ISO 15848-1, API 624

MATERIAL OF CONSTRUCTION
Body / Bonnet / Yoke	Carbon & Low Carbon Steel, Stainless Steel, Nickel alloys, High Temp Alloys, Duplex Stainless Steel, Exotic Materials
Trim	Stainless Steel, Nickel alloys,Duplex Stainless Steel, Exotic Materials
Seat	HF-Metal to Metal Seats, others upon request
Stem Packing & Seals	PTFE/ RPTFE/ Special filled PTFE/ Graphite/ Graphoil
Gaskets	PTFE/ RPTFE/ Special filled PTFE/ Graphite/ Graphoil/ Spiral Wounded
Fasteners	ASTM A193 Gr.B7/ A194 Gr.2H, B7M/ 2HM, B8/ 8, B8M/ 8M, L7/ 4, B16/ 2H etc.,

Note : For Bigger sizes please contact PR-Fect Valves
