PRODUCT DETAILS
SIZES	1/2" TO 24"
PRESSURE CLASS RATINGS	ASME #150 TO #2500
END CONNECTION	SCREWED, SOCKET WELD, FLANGED, BUTT-WELD
CONSTRUCTION TYPES	SINGLE PIECE, TWO PIECE & THREE PIECE CONSTRUCTIONS
PORT OPTIONS	FULL PORT & REGULAR PORT
SALIENT FEATURES	FIRE-SAFE DESIGN, CRYOGENIC CONFIGURATION, STEM EXTENSION, CAVITY PRESSURE RELIEF MECHANISM, ANTISTATIC FEATURE, HIGH INTEGRITY STEM SEALING, BLOWOUT-PROOF STEM, DBB PRIMARY METAL AND SECONDARY SOFT SEAT DESIGN, LOCKING ARRANGEMENTS
OPERATOR / ACTUATOR	LEVER, GEAR, ACTUATOR (PNEUMATIC, HYDRAULIC, ELECTRO-HYDRAULIC AND ELECTRIC MOTORISED)

STANDARDS SPECIFICATIONS
DESIGN & MANUFACTURE	BS 6364 / API 6D/ ISO 14313/ API 608 / BS EN ISO 17292 /API 6A / ASME B16.34
FACE TO FACE	ASME B16.10, MFG STANDARD
END CONNECTIONS	ASME B16.11, ISO 7-1, BS 21 ASME B1.20.1, ASME B16.5 RF/FF/RTJ ASME 16.25, EN 1092
TESTING	API 6D, API 598, ASME B16.34, BS EN 12266, ISO 5208, BS 6364
FIRE SAFE TESTING	ISO 10497/ API 607, API 6FA
NACE	NACE MR0175 / ISO 15156 AND NACE MR0103 / ISO17945
FUGITIVE EMISSION	ISO 15848-1, API 641
LEAK TIGHTNESS	ISO 5208, ANSI/FCI 70-2

MATERIAL OF CONSTRUCTION
BODY / END CONNECTOR	LOW CARBON STEEL, STAINLESS STEEL, DUPLEX STAINLESS STEEL
TRIM	STAINLESS STEEL, DUPLEX STAINLESS STEEL
SEAT	PTFE/ RPTFE/ SPECIAL FILLED PTFE / METAL SEATS
STEM PACKING & SEALS	PTFE/ RPTFE/ SPECIAL FILLED PTFE/GRAPHITE/GRAPHOIL
GASKETS	PTFE/ RPTFE/ SPECIAL FILLED PTFE/GRAPHITE/GRAPHOIL/SPIRAL WOUNDED
STEM BEARING	RPTFE/ SPECIAL FILLED PTFE/GRAPHITE
FASTENERS	ASTM A193 GR.B7/A194 GR.2H, B7M/2HM, B8/8, B8M/8M, L7/4, B16/2H ETC.,
SPRINGS	INCONEL X-750, STAINLESS STEEL

Note : For Bigger sizes please contact PR-Fect Valves
