| PRODUCT DETAILS |
| SIZES
| 1/ 2" TO 24"
|
| PRESSURE CLASS RATINGS
| ASME #150 TO #2500
|
| END CONNECTION
| SCREWED, SOCKET WELD, FLANGED, BUTT-WELD
|
| CONSTRUCTION TYPES
| SINGLE PIECE, TWO PIECE & THREE PIECE CONSTRUCTIONS
|
| PORT OPTIONS
| FULL PORT & REGULAR PORT
|
| SALIENT FEATURES
| FIRE-SAFE DESIGN, CRYOGENIC CONFIGURATION, STEM EXTENSION, CAVITY PRESSURE RELIEF MECHANISM,
ANTISTATIC FEATURE,
HIGH INTEGRITY STEM SEALING, BLOWOUT-PROOF STEM, DBB
PRIMARY METAL AND SECONDARY SOFT SEAT DESIGN, LOCKING ARRANGEMENTS
|
| OPERATOR/ ACTUATOR
| LEVER, GEAR, ACTUATOR (PNEUMATIC, HYDRAULIC, ELECTRO-HYDRAULIC AND ELECTRIC MOTORISED)
|
| STANDARDS SPECIFICATIONS |
| DESIGN & MANUFACTURE
| BS 6364/ API 6D/ ISO 14313/ API 608/ BS EN ISO 17292 / API 6A/ ASME B16.34
|
| FACE TO FACE
| ASME B16.10, MFG STANDARD
|
| END CONNECTIONS
| ASME B16.11, ISO 7-1, BS 21
ASME B1.20.1, ASME B16.5 RF/ FF/ RTJ
ASME 16.25, EN 1092
|
| TESTING
| API 6D, API 598, ASME B16.34, BS EN 12266, ISO 5208, BS 6364
|
| FIRE SAFE TESTING
| ISO 10497/ API 607, API 6FA
|
| NACE
| NACE MR0175/ ISO 15156 AND NACE MR0103/ ISO17945
|
| FUGITIVE EMISSION
| ISO 15848-1, API 641
|
| LEAK TIGHTNESS
| ISO 5208, ANSI/ FCI 70-2
|
| MATERIAL OF CONSTRUCTION |
| BODY/ END CONNECTOR
| CARBON & LOW CARBON STEEL, STAINLESS STEEL, NICKEL ALLOYS,
DUPLEX STAINLESS STEEL, EXOTIC MATERIALS
|
"
| TRIM
| STAINLESS STEEL, NICKEL ALLOYS, DUPLEX STAINLESS STEEL, EXOTIC MATERIALS
|
| SEAT
| PTFE/ RPTFE/ SPECIAL FILLED PTFE/ METAL SEATS
|
| STEM PACKING & SEALS
| PTFE/ RPTFE/ SPECIAL FILLED PTFE/ GRAPHITE/ GRAPHOIL
|
| GASKETS
| PTFE/ RPTFE/ SPECIAL FILLED PTFE/ GRAPHITE/ GRAPHOIL/ SPIRAL WOUNDED
|
| STEM BEARING
| RPTFE/ SPECIAL FILLED PTFE/ GRAPHITE
|
| FASTENERS
| ASTM A193 GR.B7/ A194 GR.2H, B7M/ 2HM, B8/ 8, B8M/ 8M, L7/ 4, B16/ 2H ETC.,
|
| SPRINGS
| INCONEL X-750, STAINLESS STEEL
|
