PRODUCT DETAILS
SIZES	1/ 4" TO 12"
PRESSURE CLASS RATINGS	ASME #150 TO #1500
END CONNECTION	SCREWED, SOCKET WELD, FLANGED
CONSTRUCTION TYPES	TWO PIECE & THREE PIECE CONSTRUCTIONS
PORT OPTIONS	FULL PORT & REGULAR PORT
SALIENT FEATURES	FIRE-SAFE DESIGN, CRYOGENIC CONFIGURATION, STEM EXTENSION, CAVITY PRESSURE RELIEF MECHANISM, ANTISTATIC FEATURE, HIGH INTEGRITY STEM SEALING, BLOWOUT-PROOF STEM, PRIMARY METAL AND SECONDARY SOFT SEAT DESIGN, LOCKING ARRANGEMENTS
OPERATOR/ ACTUATOR	LEVER, GEAR, ACTUATOR (PNEUMATIC, HYDRAULIC, ELECTRO-HYDRAULIC AND ELECTRIC MOTORISED)

STANDARDS SPECIFICATIONS
DESIGN & MANUFACTURE	ASME B16.34
FACE TO FACE	MFG STANDARD
END CONNECTIONS	ASME B16.11, ISO 7-1, BS 21 ASME B1.20.1, ASME B16.5 RF/ FF/ RTJ ASME 16.25, EN 1092
TESTING	API 6D, API 598, ASME B16.34, BS EN 12266, ISO 5208
FIRE SAFE TESTING	ISO 10497/ API 607, API 6FA
NACE	NACE MR0175/ ISO 15156 AND NACE MR0103/ ISO17945
FUGITIVE EMISSION	ISO 15848-1, API 641
LEAK TIGHTNESS	ISO 5208, ANSI/ FCI 70-2

""

MATERIAL OF CONSTRUCTION
BODY/ END CONNECTOR	CARBON & LOW CARBON STEEL, STAINLESS STEEL, NICKEL ALLOYS, ALUMINIUM BRONZE, DUPLEX STAINLESS STEEL, EXOTIC MATERIALS
TRIM	STAINLESS STEEL, NICKEL ALLOYS, DUPLEX STAINLESS STEEL, EXOTIC MATERIALS
SEAT	PTFE/ RPTFE/ SPECIAL FILLED PTFE/ PEEK/ DEVLON/ SS316 + ST
STEM PACKING & SEALS	PTFE/ RPTFE/ SPECIAL FILLED PTFE/ GRAPHITE/ GRAPHOIL
GASKETS	PTFE/ RPTFE/ SPECIAL FILLED PTFE/ GRAPHITE/ GRAPHOIL/ SPIRAL WOUNDED
STEM BEARING	RPTFE/ SPECIAL FILLED PTFE/ GRAPHITE
FASTENERS	ASTM A193 GR.B7/ A194 GR.2H, B7M/ 2HM, B8/ 8, B8M/ 8M, L7/ 4, B16/ 2H ETC.,

Note : For Bigger sizes please contact PR-Fect Valves
