PRODUCT DETAILS
Sizes	2" to 16"
Pressure Class Ratings	Asme #150 to #2500
End Connection	Screwed, Socket Weld, Flanged, Butt-Weld
Construction Types	O.S & Y. Rising Stem,Straight & Y - Pattern, others upon request
Salient Features	Pressure Seal,Bellow Seal,Fugitive Emissions,Metal Seats ,Back Seating,Stem Extension,Bypass Arrangement,Locking Arrangements etc.
Operator / Actuator	Handwheel, Gear, Actuator (Pneumatic, Hydraulic, Electro-Hydraulic and Electric Motorised)

15848-1, API 624

STANDARDS SPECIFICATIONS
Design & Manufacture	API 623,BS 1873, ASME B16.34
Face To Face	ASME B16.10, MFG Standard
End Connections	ASME B16.11,ISO 7-1,BS 21 ASME B1.20.1,ASME B16.5/ B16.47 RF/FF/RTJ ASME 16.25,EN 1092
Testing	API 598, ASME B16.34,BS6364
Fire safe testing	ISO 10497/ API 607,API 6FA
Nace	NACE MR0175 / ISO 15156 and NACE MR0103 / ISO17945
Fugitive emission	ISO 15848-1, API 624

MATERIAL OF CONSTRUCTION
Body / Bonnet / Yoke	Low Carbon Steel, Stainless Steel,Duplex Stainless Steel
Trim	Stainless Steel, Duplex Stainless Steel
Seat	HF-Metal to Metal Seats, others upon request
Stem Packing & Seals	PTFE/ RPTFE/ Special filled PTFE/Graphite/Graphoil
Gaskets	PTFE/ RPTFE/ Special filled PTFE/Graphite/Graphoil/Spiral Wounded
Fasteners	ASTM A193 Gr.B7/A194 Gr.2H, B7M/2HM, B8/8, B8M/8M, L7/4, B16/2H etc.,

Note : For Bigger sizes please contact PR-Fect Valves
